| Characteristics |
Practical |
Initial |
Saturation magnetic |
Curie |
Specific |
Relative |
Relative Temperature |
詳細
|
|
Frequency |
Permeability |
flux density |
Temperature |
Gravity |
Loss Factor |
coefficient |
|
特性 |
使用頻率 |
初透磁率 |
飽和磁束密度 |
居里溫度 |
比重 |
比損耗因子 |
初透磁率比溫度系數 |
| Material |
ft(MHZ) |
μiac |
BS(gauss) |
H(Oe) |
T.C(℃) |
d(g/cm3) |
tanδ/μi (x10-6MHZ) |
αμr
(x10-6/℃ 20℃~70℃) |
|
| 材質 |
| C4A |
0.1-2.0 |
500 |
3400 |
30 |
>200 |
4.6 |
<150 2.0 |
3-12 |
More... |
| C5 |
0.1-1.0 |
750 |
2750 |
30 |
>130 |
4.8 |
<280 1.0 |
2-5 |
More... |
| C5A |
0.1-1.0 |
650 |
3150 |
30 |
>140 |
4.8 |
<250 1.0 |
0-7 |
More... |
| C5C |
0.01-0.5 |
1000 |
2700 |
30 |
>130 |
4.8 |
<100 0.5 |
2-8 |
More... |
| C6 |
0.01-0.5 |
1300 |
2650 |
30 |
>100 |
4.7 |
<75 0.5 |
0-3 |
More... |
| EIB |
0.1-2.0 |
550 |
1980 |
30 |
>125 |
4.6 |
<90 2.0 |
8-35 |
More... |
| EIC |
0.1-2.0 |
200 |
2700 |
30 |
>200 |
4.7 |
<110 2.0 |
3-10 |
More... |
| EID |
0.3-15 |
90 |
3300 |
30 |
>300 |
4.8 |
<850 15 |
4-8 |
More... |
| E2 |
0.1-5.0 |
160 |
3400 |
30 |
>150 |
4.6 |
<100 5.0 |
25-65 |
More... |
| E23 |
0.1-12 |
120 |
3000 |
30 |
>150 |
4.4 |
<130 12 |
40-100 |
More... |
| E2D |
0.1-3.0 |
300 |
2500 |
30 |
>150 |
4.5 |
<60 2.0 |
10-30 |
More... |
| E2F |
0.1-2.0 |
400 |
2700 |
30 |
>150 |
4.8 |
<60 1.0 |
30-150 |
More... |
| E3 |
0.4-20 |
80 |
2750 |
30 |
>300 |
4.4 |
<160 20 |
55-130 |
More... |
| F1B |
0.3-7.0 |
250 |
3000 |
30 |
>180 |
6.1 |
<705 7.0 |
15-35 |
More... |
| F3B |
0.1-2.0 |
280 |
3180 |
30 |
>150 |
4.9 |
<65 2.0 |
10-30 |
More... |
| F4D |
0.1-1.0 |
500 |
3000 |
30 |
>250 |
4.7 |
<50 0.5 |
10-20 |
More... |
| F4F |
0.1-1.0 |
180 |
3700 |
30 |
>270 |
4.8 |
<250 0.5 |
40-160 |
More... |
| F5D |
0.05-2 |
400 |
3700 |
30 |
>250 |
4.9 |
<80 1.0 |
15-25 |
More... |
| F6D |
0.05-3 |
200 |
4100 |
30 |
>300 |
4.9 |
<65 3.0 |
20-30 |
More... |
| F7D |
0.05-1 |
700 |
3900 |
30 |
>180 |
5.1 |
<80 1.0 |
7-15 |
More... |
| F8 |
0.3-7.0 |
200 |
3700 |
30 |
>250 |
4.7 |
<350 7.0 |
19-32 |
More... |
| Y5E |
20-120 |
20 |
1950 |
30 |
>250 |
4.9 |
<500 100 |
2-10 |
More... |
| Y8B |
0.5-20 |
60 |
3250 |
30 |
>300 |
4.5 |
<400 20 |
5-15 |
More... |
| Y8C |
0.5-15 |
100 |
2000 |
30 |
>300 |
4.8 |
<250 15 |
5-15 |
More... |
| Y8L |
05-15 |
80 |
2650 |
30 |
>300 |
4.8 |
<1100 15 |
3-9 |
More... |
| Y9 |
0.5-30 |
65 |
3400 |
30 |
>300 |
4.8 |
<280 30 |
25-65 |
More... |
| Y9D |
1.0-50 |
50 |
3400 |
30 |
>300 |
4.8 |
<600 50 |
30-80 |
More... |
| Y11 |
3.0-80 |
40 |
2800 |
30 |
>350 |
4.5 |
<400 60 |
50-70 |
More... | |
材料一览
